50 Ton Truck Weighing Load Cell Sensor 2.0mv/v Output

50 Ton Truck Weighing Load Cell Sensor 2.0mv/v Output

Detalhes do produto:
Lugar de origem: China
Marca: RJ
Certificação: CE/ROSE
Número do modelo: RJ
Informações detalhadas
Lugar de origem:
China
Marca:
RJ
Certificação:
CE/ROSE
Número do modelo:
RJ
Saída:
2,0vm/v
Capacidade:
3~120kg
Output nominal:
2.0±0.2
Não-linearidade:
0,03%FS
Histerese:
0,03%FS
Repetitividade:
0,03%FS
Destacar:

High Light

Destacar:

50 ton load cell sensor

,

truck weighing load cell

,

2.0mv/v output load cell

Informações de negociação
Quantidade de ordem mínima:
1
Preço:
$5-10
Detalhes da embalagem:
caixa ou caixa de madeira
Tempo de entrega:
5-8 dias úteis
Termos de pagamento:
L/C, D/A, D/P, T/T, Western Union
Habilidade da fonte:
2000PC/Month
Descrição do produto

Truck 50 Ton Weighing Scale Load Cell

50 Ton Truck Weighing Load Cell Sensor 2.0mv/v Output 0


Load cells are used in smart devices, smart vending cabinets, smart garbage bins, weight detection equipment, etc., and are easy to install and operate.

Specifications
Rated Output
mv/v
2.0±0.2
Non-linearity
%F.S
0.03%F.S
Hysteresis
%F.S
0.03
Repeatability
%F.S
0.03
Creep
%F.S/3min
0.03
Temp.effect on zero
%F.S/10℃
0.03%F.S
Temp.effect on span
%F.S/10℃
0.05%F.S
Zero balance
mv/v
±0.05
Input impedance
Ω
405±6
Output impedance
Ω
350±5
Insulation resistance
≥2000(100VDC)
Recommended excitation voltage
VDC
3~12
Allowed excitation voltage
VDC
3~12
Compensated temp.Range
-10℃~+40℃
Operating temp.Range
0℃~+40℃
Safe overload
%F.S
120
Ultimate Overload
%F.S
150
Connection
Excitation: Red:+ Black:-
Signal: Green:+ White:-

50 Ton Truck Weighing Load Cell Sensor 2.0mv/v Output 1

Packing & Transport



50 Ton Truck Weighing Load Cell Sensor 2.0mv/v Output 2

FAQ

Q: How can I get the quotation?
Please send your inquiry to us.
Click 'Contact Supplier' icon which is on the right-side or write down your requirement at the bottom of this page.


Q: What detailed information do I need to provide if I want to place an order?

We need to know the following information:
Capacity, Usage and other related parameters you need.


Q: Do you have any discount?
Yes, we take bulk order, if you buy large QTY, please send us inquiry, we can discuss the price.

Q: Can I get samples?
Yes, if you have the follower orders, we could offer the samples or free samples for you.

Q: How about the quality of the products?
We have the certification of CE and RoHs , also we are the Alibaba's verified supplier, you don't have to worry about this.

Q: When will you arrange the production?
We will arrange the production immediately after receiving your payment.

Q: Could you provide me the shortest lead time?
We have materials in our stock, if you really need, let's discuss and we will try our best to satisfy you.
